BYCON Abrasive Diamond Concrete Grinding Wheels

High-performance diamond grinding wheels for concrete and stone surfaces. Available in multiple styles for fast, clean material removal in wet or dry conditions.

Product successfully added to the Quote List

SKU: DIAMOND GRINDING WHEELS SERIES Categories: Diamond Grinding Wheels, Grinding & Wire Cutting

Super Effective Abrasive Diamond Concrete Grinding Wheel

Efficient grinding performance on concrete and stone surfaces
Designed for high-speed grinding and surface preparation, these diamond wheels ensure fast material removal on concrete, granite, tile and other surfaces—whether dry or wet.

These abrasive grinding wheels from BYCON are built for durability and speed. With a range of configurations in tooth count, segment size, and cup shape, there’s a model available for every grinding application. The open segment layout helps reduce loading or clogging, while the various options in teeth and matrix deliver precision in demanding environments. Available in multiple diameters to fit most standard grinders.

Key Features

Open segment layout: Reduces risk of clogging during grinding
Wet & dry compatible: Suitable for both grinding methods
Multi-material use: Designed for concrete, granite, tile, and more
High diamond concentration: Ensures long tool life and aggressive performance
Custom styles available: Various tooth styles and cup types based on application

What’s Included

Selected Diamond Grinding Wheel (based on model)
Pre-mounted arbor hole
Optional color and layout based on order

Technical Specifications

Art Number	Diameter (mm)	Segment Type	Segment Size (mm)	Teeth	Arbor Size (mm)
3041180	180	Single Row	H: 8	3	22.23
3042180	180	Double Row	H: 8	6	22.23
3043180	180	Turbo Row	H: 5	9	22.23
3031125	125	Arrow	T: 6 / W: 20	3	22.23
3031180	180	Arrow	T: 6 / W: 20	7	22.23
3033125	125	Swirl	T: 5 / W: 7	16	22.23
3033180	180	Swirl	T: 5 / W: 7	24	22.23
3034125	125	Turbo Segment	T: 5 / W: 6/12	14	22.23
3034180	180	Turbo Segment	T: 5 / W: 6/11	18	22.23
3032105	105	PCD	T: 1.5 / W: 3 / L: 4	9	22.23
3032115	115	PCD	T: 1.5 / W: 3 / L: 4	9	22.23
3032125	125	PCD	T: 1.5 / W: 3 / L: 4	9	22.23
3032150	150	PCD	T: 1.5 / W: 3 / L: 4	12	22.23
3032180	180	PCD	T: 1.5 / W: 3 / L: 4	12	22.23
