BYCON DB-132 Diamond Dry Core Drill M18 1 1/4” 1500W

BYCON DB-132 Diamond Dry Core Drill M18 1 1/4” 1500W | Micro Percussion

Unmatched Drilling Performance: Dry drilling up to 132mm in concrete with brushless motor & soft percussion function
Ultra Lightweight: Weighs only 3.7 kg, reducing operator fatigue
Enhanced Efficiency: Micro-percussion mode ensures cleaner, more precise holes
Versatile Use: Drills through reinforced concrete, brick, limestone, and abrasive materials
Long-Lasting Performance: Brushless motor technology reduces wear and extends tool lifespan
Bonus Accessory: FREE (Suction) Adapter M18 – 1 1/4” included

Powerful & Versatile Dry Core Drill for Professionals

The BYCON DB-132 Diamond Dry Core Drill is designed for demanding applications in construction and renovation. With its brushless motor and micro-percussion drilling mode, it excels in dry drilling up to 132mm in concrete and 202mm in masonry, making it an excellent choice for HVAC installations, electrical work, and plumbing.

Optimized for Hard Materials: Easily drills through reinforced concrete and high-density building materials
Two-Speed Operation: Select between 72mm at speed 1 or 132mm at speed 2 for optimal performance
High Torque & Percussion Rate: Delivers 14 Nm torque and up to 48,000 bpm, ensuring fast and effective drilling
Brushless Motor Advantage: Provides longer lifespan, less maintenance, and continuous smooth operation

📌 Note: This tool is ideal for installing conduits, electrical wiring, ventilation systems, and more.

What’s Included?

BYCON DB-132 Diamond Dry Core Drill M18 1500W
Adapter M18 – M16 (for box drill connection)
Adjustable Handle with Built-in Level
Wrench Set: M22 / M24
SDS-Plus Drill Bit 8 x 150 mm
FREE (Suction) Adapter M18 – 1 1/4”
User Manual

Power Output	1500W
Voltage	230V / 50-60Hz
Current Draw	10A
Weight	3.7 kg
Max Concrete Diameter	132 mm
Max Masonry Diameter	202 mm
No-Load Speed	1,530 / 3,060 rpm
Impact Rate	24,000 / 48,000 bpm
Torque	14 Nm
Connection Type	M18
